IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty

Sertifikasi
CINA crown extra lighting co. ltd Sertifikasi
CINA crown extra lighting co. ltd Sertifikasi
I 'm Online Chat Now

IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty

IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty
IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty

Gambar besar :  IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty

Detail produk:
Tempat asal: Jiangsu, Cina
Nama merek: Crown Extra
Sertifikasi: ATEX,CE,ROHS,CNEX,ISO9001
Nomor model: Bys
Syarat-syarat pembayaran & pengiriman:
Kuantitas min Order: 1 pc
Harga: USD32-40 per pc
Waktu pengiriman: 15 hari kerja
Syarat-syarat pembayaran: T/t
Menyediakan kemampuan: 50000pcs/bulan

IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty

Deskripsi
Merek: Mahkota ekstra Nama Produk: Lampu Linear Tahan Ledakan BYS
Perumahan: Polyester yang diperkuat serat-kaca Cri: RA: ≥70
Efisiensi: 100lm/w Bersertifikat: CNEX, EX, IP66, IEC, IECEX
CCT: 5500-6500K,suhu warna lainnya dapat disesuaikan Sudut balok: 120-140 °
Pemasangan: Plafon, Dinding, Flange, Liontin
Menyoroti:

IP66 explosion proof fluorescent light

,

GRP material fluorescent light with warranty

,

high efficiency explosion proof light

IP66 9-54w Explosion-proof fluorescent Light GRP material 100ml/w efficiency 5 Years Warranty





BYS Series



Features:

1.GRP enclosure, corrosion-proof, Polycarbonate lampshade, strip-shaped with anti-glare
2.Special locking mechanism, with reliable locking force
3.Built-in explosion proof interlockdevice, automatically power-off after cover open
4.The emergency device can be equipped




Applications


A wide range of hazardous areas where ignitable vapors, dust, moisture and corrosive elements are present
Areas requiring frequent on-and-off of lights or power cycling- no warm up time required
Typical applications include:
Oil and gas industries
Chemical, petrochemical
Pharmaceutical industries
Pulp and Paper
Waste and sewage treatment
Power Generation
Other high humidity, high dust, high temperature, vapor locations




Standard Materials
Housing: Fiber-glass reinforced polyester
Exterior: Stainless steel
Globe: Polycarbonate, anti-glare
Gasket: Silicon rubber




Certifications
ATEX
CNEX
CE
RoHS
ISO9001



IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty 0







Electrical Data
Ex Marking Ex d e IIC T6 Gb/ DIP A21 TA
Classification Group II, Catogory 2 GD; Class I, Division 1 and 2,Group A,B,C,D;
IP Degree IP66
Corrosion Resistant WF2
Rated Voltage 110VAC; 220VAC/50~60HZ
Battery Back-up Optional, Emergency time>90min;Charging time:24h;Starting time:0.3s
Conduit Entries G 3/4"
Terminal ≤2.5mm2
Mounting Styles Pendant; Ceiling; Chain; Embedded; Wall; Stanchion




Ordering Information
Model NO. BYS-600 BYS-1200
T8 Fluorescent tube (1-3)*18Watt (1350Lm,75Lm/W) (1-3)*36Watt (2700Lm,75Lm/W)
T5 Fluorescent tube (1-3)*14Watt(1350Lm,96Lm/W) (1-3)*28Watt (2100Lm,75Lm/W)
LED tube (1-3)*8Watt (800Lm,100Lm/W) (1-3)*18Watt (1800Lm,100Lm/W)



IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty 1



Installation Instructions:
Before installation, check voltage, power and other parameters carefully and
make installation preparations arrordingly to layout circuit.
1. organize firstly supporting spare parts and accessories
2. do shut off power before installation
3. the loading capacity of the ceilingfixed item where the lamp is installed should be the same as the lamp weight
4. do power-on test to make sure the lamp can be lighted
5. make sure the lamp is installed firmly, turn on the light finally
Company information:
Crown Extra Lighting Co., Ltd. is a comprehensive enterprise integrating R&D, production, sales and service.
The company is located in Changzhou, known as the "Dragon City" in the Yangtze River
Delta of China. The company is committed to becoming a provider of green, environmentally friendly,
energy-saving, and leading industrial lighting solutions, providing high-quality lighting products for
petroleum, petrochemical, electric power, metallurgy, railways, aerospace, military, public security,
fire fighting, ships, roads, pharmaceuticals, etc. And professional technical service programs.
FAQ:
Q1. Can I have a sample order for explosion-proof led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What kind of payments do you accept?
A:T/T, L/C, Western Union,, MoneyGram, etc..
Q3:What is you main products?
A: Explosion-proof LED light ,explosion-proof box,explosion proof fittings, etc.
Q4: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q5: What's the MOQ?
A:MOQ is 1 set.

IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty 2

IP66 9-54w Explosion Proof Fluorescent Light GRP Material 100ml/w Efficiency 5 Years Warranty 3
